Drawing and Engineering Review
We review mating surfaces and interface dimensions and assess material, heat treatment and manufacturing feasibility.
Legacy FLSmidth clinker cooler installations
Identify legacy FLSmidth clinker coolers. Following the cement business sale on 2025-10-31, confirm spares by nameplate, model and drawing.
Legacy cement equipment
Select Your Crusher Type
FLSmidth completed the sale of its cement business on 2025-10-31. Clinker coolers are therefore covered here as legacy installations outside the current FLS mining equipment range. Identify grate plates, side plates, supports and drive spares from the original nameplate, full model designation, drawing and revision.
FLS
Component Location Diagram
The numbers on the diagram correspond one to one with the rows below.
| No. | Component | Location | Applies to |
|---|---|---|---|
| 1 | Cross bars | Transverse conveying bars above the cooling bed | Cross-Bar Cooler (2024 brochure design) |
| 2 | Stationary grate modules | Bed surface below the cross bars | Cross-Bar Cooler (2024 brochure design) |
| 3 | Support frame | Below the cooling bed | Cross-Bar Cooler (2024 brochure design) |
