2012 · 2 models
Select a model to jump to its component table; former and renamed designations are listed under “Historical names / renamings”.
| Model | Historical names / renamings | Period | Components |
|---|---|---|---|
| CSI Cyclone Pro D-Series | CSI-D4; CSI-D5; CSI-D3; Cyclone Pro D-Series | 2012 | 5 |
| CSI Cyclone E-Series | CSI-03; CSI-04; Cyclone E-Series | 2012 | 5 |
The numbers on the diagram correspond one to one with the rows below.
| No. | Component | Location | Applies to |
|---|---|---|---|
| 1 | Screen basket | Left-hand conical screen surface in the cutaway | CSI-D3;CSI-D4;CSI-D5;Cyclone Pro D-Series |
| 1 | Drive motor | Vertical drive motor on the right | CSI-03;CSI-04;Cyclone E-Series |
| 2 | Scraper flight | Rotating flights inside the screen basket | CSI-D3;CSI-D4;CSI-D5;Cyclone Pro D-Series |
| 2 | Upper access hatch | Trapezoidal access hatch on the upper housing | CSI-03;CSI-04;Cyclone E-Series |
| 3 | Spray bar | Cleaning spray pipe beside the left-hand screen | CSI-D3;CSI-D4;CSI-D5;Cyclone Pro D-Series |
| 3 | Lower access hatch | Rectangular access hatch on the lower housing | CSI-03;CSI-04;Cyclone E-Series |
| 4 | Conical launder | Conical liquid collection launder below the basket | CSI-D3;CSI-D4;CSI-D5;Cyclone Pro D-Series |
| 5 | Side access hatch | Access hatch on the lower right-hand side | CSI-D3;CSI-D4;CSI-D5;Cyclone Pro D-Series |
| Component |
|---|
| Ceramic liner |
| Gearbox |
Models with the same components are grouped together; select a group to open its component table.
Models: CSI Cyclone Pro D-Series, CSI Cyclone E-Series
| No. | Component |
|---|---|
| 1 | Screen basket |
| 2 | Scraper blade |
| 3 | Model-specific component |
| Ceramic liner | |
| Gearbox |
The Elgin CSI Cyclone E-Series / Cyclone Pro D-Series Vertical Cuttings Dryers covers 2 models: CSI Cyclone Pro D-Series, CSI Cyclone E-Series. Former and renamed designations are listed in the models table on this page.
The Elgin CSI Cyclone E-Series / Cyclone Pro D-Series Vertical Cuttings Dryers is also documented under these designations: CSI Cyclone Pro D-Series, CSI-D4, CSI-D5, CSI-D3, Cyclone Pro D-Series, CSI Cyclone E-Series, CSI-03, CSI-04, Cyclone E-Series.
The Elgin CSI Cyclone E-Series / Cyclone Pro D-Series Vertical Cuttings Dryers is listed under the TerraSource Global brand. Period: 2012. Status: Historical model.
5 components are recorded, including: Screen basket, Scraper blade, Ceramic liner, Gearbox and more. The full list with locations is in the components table on this page.
