Grinding path spacer strip
Maintains grinding path spacing, supports liners and defines a controlled secondary crushing passage.
Grinding path spacer strip (Grinding Path Spacer Strip)— Hammer Crusher Wear part, position 18.
Location and Function
| Material Options | Quenched and tempered alloy steel, wear-resistant steel or a surface-hardfaced strip |
| Typical Properties and Acceptance Criteria | Spacer and grinding strips maintain grinding path geometry and material passages while carrying high local contact pressures and abrasive wear. Control cross-section, length, straightness, hardness gradient, fastening, end cracks and height relative to the liners. Changing strip height directly changes crushing clearance and product fineness. |
| Principal Failure Mechanism | Impact, cutting and abrasion |
Information Required for RFQ
- Equipment manufacturer, machine model, serial number, model details and latest drawing revision;
- Part dimensions, unit weight, key tolerances, assembly and fastening method;
- Current material, chemical composition, heat treatment, hardness and mechanical property reports;
- Processed material, maximum particle size, hardness/abrasiveness, moisture and tramp material records;
- Speed, load, temperature, pressure, process medium chemistry and continuous operating time;
- Failure photographs, wear measurements, crack/fracture locations and current service life;
Materials and values are for preliminary engineering selection. Final chemical composition, heat treatment, hardness and dimensional tolerances must follow the OEM drawings and technical agreement.
