What other names or designations is the Cylindrical pebble mill known by?
The Cylindrical pebble mill is also documented under these designations: Marcy Pebble Mill.
Cylindrical pebble mill
Cylindrical pebble mill · 1 model
Marcy
MarcyBrand
Cylindrical pebble millEquipment type
Historical modelStatus
Marcy
Models and Historical Names in This Series
Select a model to jump to its component table; former and renamed designations are listed under “Historical names / renamings”.
| Model | Components |
|---|---|
| Marcy Pebble Mill | 3 |
Marcy
Numbered Components
The numbers on the diagram correspond one to one with the rows below.
| No. | Component | Location | Applies to |
|---|---|---|---|
| 1 | Mill shell | Cylindrical shell surrounding the inner lining | 4×16ft catalog specification; shell cutaway only |
| 2 | Alumina ceramic lining bricks | Inner shell wall; lining variant selected for this section | 4×16ft catalog specification; shell cutaway only |
| 3 | Grinding media | Grinding chamber inside the lining | 4×16ft catalog specification; shell cutaway only |
Marcy
Components by Model
Models with the same components are grouped together; select a group to open its component table.
Marcy Pebble Mill3 items
| No. | Component | Location |
|---|---|---|
| 2 | Alumina ceramic lining brick | Cylindrical grinding chamber lining |
| 3 | Grinding media | Inside the grinding chamber |
| Non-metallic pad | Cylindrical grinding chamber lining |
Frequently asked questions
Which brand and type of equipment is the Cylindrical pebble mill?
The Cylindrical pebble mill is listed under the Marcy brand as: Cylindrical pebble mill. Status: Historical model.
Which components and wear parts are recorded for the Cylindrical pebble mill?
3 components are recorded, including: Non-metallic pad, Alumina ceramic lining brick, Grinding media. The full list with locations is in the components table on this page.
Which model-specific components of the Cylindrical pebble mill have their own page?
Model-specific components with their own page: Non-metallic pad, Alumina ceramic lining brick, Grinding media (3 in total).
How do I enquire about parts for the Cylindrical pebble mill?
Send us a drawing or sample and tell us the equipment model and part name.
