Which models does the XH cover?
The XH covers 6 models: 5142-32XH, 5162-32XH, 6162-38XH, 6202-38XH, 7202-38XH, 8202-38XH. Former and renamed designations are listed in the models table on this page.
XH
2018 · 6 models
JCI
JCIBrand
2018Period
Historical modelStatus
JCI
Numbered Components
The numbers on the diagram correspond one to one with the rows below.
| No. | Component | Location | Applies to |
|---|---|---|---|
| 1 | Exciter housing | Central exciter housing on the screenbox side | OEM Horizontal Screens family side view (exact FS/XH specification not specified) |
| 2 | Screenbox side plate | Upper screenbox side plate and stiffening members | OEM Horizontal Screens family side view (exact FS/XH specification not specified) |
| 3 | Support base | Continuous support base beneath the screenbox | OEM Horizontal Screens family side view (exact FS/XH specification not specified) |
Other Components · 9 items
| Component |
|---|
| Screen media |
| Feed box liner |
| Discharge lip liner |
| Spherical roller bearings |
| Screen support springs / buffers |
| Screen tension rails |
| Drive belts |
| Exciter shaft assembly |
| Stepped grizzly bars |
JCI
Components by Model
Models with the same components are grouped together; select a group to open its component table.
5142-32XH, 5162-32XH, 6162-38XH, 6202-38XH, 7202-38XH, 8202-38XH9 items
Models: 5142-32XH, 5162-32XH, 6162-38XH, 6202-38XH, 7202-38XH, 8202-38XH
| Component | Location |
|---|---|
| Screen Mesh / Wire Mesh | |
| Feed Box Liner | |
| Model-specific component | |
| Model-specific component | |
| Support Spring / Buffer | Between the screen box and the base frame |
| Tension Rail / Wedge | |
| Drive belt | |
| Exciter shaft assembly | Exciter mechanism in the middle of the screen box |
| Stepped bar | Upper coarse screen deck |
Frequently asked questions
What other names or designations is the XH known by?
The XH is also documented under these designations: 5142-32XH, 5162-32XH, 6162-38XH, 6202-38XH, 7202-38XH, 8202-38XH.
Which brand and type of equipment is the XH?
The XH is listed under the JCI brand. Period: 2018. Status: Historical model.
Which components and wear parts are recorded for the XH?
9 components are recorded, including: Screen Mesh / Wire Mesh, Feed Box Liner, Support Spring / Buffer, Tension Rail / Wedge, Drive belt, Exciter shaft assembly, Stepped bar and more. The full list with locations is in the components table on this page.
Which model-specific components of the XH have their own page?
Model-specific components with their own page: Exciter shaft assembly, Stepped bar (2 in total).
How do I enquire about parts for the XH?
Send us a drawing or sample and tell us the equipment model and part name.
