QF Three-shaft Vibrating screen
Three-shaft Vibrating screen · LP 2021 · 1 model
JCI
JCIBrand
Three-shaft Vibrating screenEquipment type
LP 2021Period
Historical modelStatus
JCI
Models and Historical Names in This Series
Select a model to jump to its component table; former and renamed designations are listed under “Historical names / renamings”.
| Model | Period | Components |
|---|---|---|
| 6204-32QF | LP 2021 | 8 |
JCI
Numbered Components
The numbers on the diagram correspond one to one with the rows below.
| No. | Component | Location | Applies to |
|---|---|---|---|
| 1 | Discharge lip liner | Metal discharge lip across the discharge end | QF OEM specification-brochure representative unit (pictured dimensions not specified) |
| 2 | Screen support springs / buffers | Black elastomer supports between the screenbox and base | QF OEM specification-brochure representative unit (pictured dimensions not specified) |
| 3 | Drive motor | Blue drive motor at the rear side of the screenbox | QF OEM specification-brochure representative unit (pictured dimensions not specified) |
| 4 | Screenbox side plate | Stiffened side plate on the right side of the screenbox | QF OEM specification-brochure representative unit (pictured dimensions not specified) |
Other Components · 6 items
| Component |
|---|
| Screen media |
| Feed box liner |
| Spherical roller bearings |
| Screen tension rails |
| Drive belts |
| Exciter shaft assembly |
JCI
Components by Model
Models with the same components are grouped together; select a group to open its component table.
6204-32QF8 items
| No. | Component | Location |
|---|---|---|
| 1 | Model-specific component | |
| 2 | Support Spring / Buffer | Between the screen box and the base frame |
| Screen Mesh / Wire Mesh | ||
| Feed Box Liner | ||
| Model-specific component | ||
| Tension Rail / Wedge | ||
| Drive belt | ||
| Exciter shaft assembly | Exciter mechanism in the middle of the screen box |
Frequently asked questions
Which brand and type of equipment is the QF Three-shaft Vibrating screen?
The QF Three-shaft Vibrating screen is listed under the JCI brand as: Three-shaft Vibrating screen. Period: LP 2021. Status: Historical model.
Which components and wear parts are recorded for the QF Three-shaft Vibrating screen?
8 components are recorded, including: Screen Mesh / Wire Mesh, Feed Box Liner, Support Spring / Buffer, Tension Rail / Wedge, Drive belt, Exciter shaft assembly and more. The full list with locations is in the components table on this page.
Which model-specific components of the QF Three-shaft Vibrating screen have their own page?
Model-specific components with their own page: Exciter shaft assembly (1 in total).
How do I enquire about parts for the QF Three-shaft Vibrating screen?
Send us a drawing or sample and tell us the equipment model and part name.
