Modular VSI crushing plant · 2026-06 · 1 model
Select a model to jump to its component table; former and renamed designations are listed under “Historical names / renamings”.
| Model | Historical names / renamings | Period | Components |
|---|---|---|---|
| Canica MV successor modular VSI series | Canica MV2000; MV2000 Canica2000SD | 2026-06 | 29 |
The numbers on the diagram correspond one to one with the rows below.
| No. | Component | Location | Applies to |
|---|---|---|---|
| 1 | Feed chute | Red feed chute above the VSI | MV2000 (2026 OEM pictured module configuration) |
| 2 | Canica 2000 VSI unit | Crusher in the centre of the module platform | MV2000 (2026 OEM pictured module configuration) |
| 3 | Galvanized walkways, stairs, handrails and skid feet | Access structures and base support of the module | MV2000 (2026 OEM pictured module configuration) |
| 4 | Ground-level lubrication unit | Lubrication unit at the lower right of the module | MV2000 (2026 OEM pictured module configuration) |
| 5 | VSI drive motor | Black vertical drive motor beside the VSI | MV2000 (2026 OEM pictured module configuration) |
| Component |
|---|
| Feed Tube — Feeding pipe |
| Anvil block or stone box |
| Ejection disc or enclosed rotor |
| Bearing Pedestal / Housing — Bearing support |
| MV2000 2021 drive motor and soft start |
| MV2000 2021 Lubricating Oil Tank |
| Bearing Pedestal / Housing — MV2000 2021 three-bearing support and Astralloy main shaft |
| MV2000 2021 cast chrome support protector |
| MV2000 2021 hopper rock cap and deflection plate |
| Feed Tube — MV2000 2021 external feeding pipe mechanism |
| Feed Tube — MV2000 2021 feeding pipe, cover and main frame liner |
| MV2000 2021 Flywheel with cast lining |
| MV2000 2021 Check Door Safety Lock |
| MV2000 2021 safety lock for opening cover |
| MV2000 2021 control panel |
| MV2000 2021 discharge chute and rubber dust cover |
| MV2000 2021 Lubrication motor/VSI motor/oil heater starting control |
| MV2000 2021 auxiliary electric control cabinet |
| MV2000 2021 emergency stop |
| MV2000 2021 automatic sequential start and stop and upstream and downstream interlocking |
| MV2000 2021 remote control interface |
| MV2000 2021 ammeter |
| MV2000 2021 removable switchgear panel (optional) |
| MV2000 2021 dual driver (optional) |
| MV2000 Hydralid hydraulic cap opening and capping mechanism |
| MV2000 off-site conveyor motor starting kit (optional) |
Models with the same components are grouped together; select a group to open its component table.
| No. | Component | Location |
|---|---|---|
| 1 | Feeding chute | Top of the body |
| 3 | MV2000 2021 Galvanized walkways, stairs, handrails and sliding seat feet | Modular steel structure |
| 4 | MV2000 2021 Floor Lubrication Unit | The bottom of the module is convenient for maintenance |
| Feed Tube — Feeding pipe | Above the rotor/disc | |
| Anvil block or stone box | Around the crushing chamber | |
| Ejection disc or enclosed rotor | Working part above the vertical shaft | |
| Bearing Pedestal / Housing — Bearing support | Vertical shaft support mechanism | |
| MV2000 2021 drive motor and soft start | VSI power system | |
| MV2000 2021 Lubricating Oil Tank | VSI oil lubrication system | |
| Bearing Pedestal / Housing — MV2000 2021 three-bearing support and Astralloy main shaft | VSI vertical shaft support; brand material name varies from material grade to | |
| MV2000 2021 cast chrome support protector | VSI bearing support exterior | |
| MV2000 2021 hopper rock cap and deflection plate | VSI top hopper | |
| Feed Tube — MV2000 2021 external feeding pipe mechanism | The hopper goes down to the top of the rotor | |
| Feed Tube — MV2000 2021 feeding pipe, cover and main frame liner | VSI upper part/inner body | |
| MV2000 2021 Flywheel with cast lining | VSI drive department | |
| MV2000 2021 Check Door Safety Lock | VSI body inspection door | |
| MV2000 2021 safety lock for opening cover | VSI cover opening mechanism | |
| MV2000 2021 control panel | Module electrical control bit | |
| MV2000 2021 discharge chute and rubber dust cover | Lower discharge of crusher | |
| MV2000 2021 Lubrication motor/VSI motor/oil heater starting control | Modular electric control cabinet | |
| MV2000 2021 auxiliary electric control cabinet | Module electrical | |
| MV2000 2021 emergency stop | Five modules; only the configurations listed in the 2021 volume | |
| MV2000 2021 automatic sequential start and stop and upstream and downstream interlocking | Module control | |
| MV2000 2021 remote control interface | Module control | |
| MV2000 2021 ammeter | Electronic control monitoring | |
| MV2000 2021 removable switchgear panel (optional) | Module electrical control interface | |
| MV2000 2021 dual driver (optional) | VSI driver configuration | |
| MV2000 Hydralid hydraulic cap opening and capping mechanism | VSI top cover and module operating platform | |
| MV2000 off-site conveyor motor starting kit (optional) | Electronic control interface of module to off-site feeding/finished product conveyor |
The Modular vertical shaft impact crushing plant is also documented under these designations: Canica MV successor modular VSI series, Canica MV2000, MV2000 Canica2000SD.
The Modular vertical shaft impact crushing plant is listed under the Canica-Jaques brand as: Modular VSI crushing plant. Period: 2026-06. Status: Historical model.
29 components are recorded, including: Feeding chute, Feed Tube, Anvil block or stone box, Ejection disc or enclosed rotor, Bearing Pedestal / Housing, MV2000 2021 drive motor and soft start, MV2000 2021 Lubricating Oil Tank, Bearing Pedestal / Housing and more. The full list with locations is in the components table on this page.
Model-specific components with their own page: MV2000 Hydralid hydraulic cap opening and capping mechanism, MV2000 off-site conveyor motor starting kit (optional) (2 in total).
