6 models
Select a model to jump to its component table; former and renamed designations are listed under “Historical names / renamings”.
| Model | Components |
|---|---|
| МШР-1500х5600 | 6 |
| МШР-3200х4500 | 6 |
| МШР-3600х4000 | 6 |
| МШР-3600х5000 | 6 |
| МШР-4000х5000 | 6 |
| МШР-4500х5000 | 6 |
The numbers on the diagram correspond one to one with the rows below.
| No. | Component | Location | Applies to |
|---|---|---|---|
| 1 | Shell | Outer wall of the cutaway shell | МШР-3200х4500;МШР-3600х4000;МШР-3600х5000;МШР-4000х5000;МШР-4500х5000 |
| 2 | End cover | End wall at the right of the shell | МШР-3200х4500;МШР-3600х4000;МШР-3600х5000;МШР-4000х5000;МШР-4500х5000 |
| 3 | Plain bearing | Bearing around the left trunnion | МШР-3200х4500;МШР-3600х4000;МШР-3600х5000;МШР-4000х5000;МШР-4500х5000 |
| 4 | Ring gear | Girth gear around the right shell end | МШР-3200х4500;МШР-3600х4000;МШР-3600х5000;МШР-4000х5000;МШР-4500х5000 |
| 5 | Drive shaft assembly | Pinion drive at the lower right | МШР-3200х4500;МШР-3600х4000;МШР-3600х5000;МШР-4000х5000;МШР-4500х5000 |
| Component |
|---|
| Lubrication station |
Models with the same components are grouped together; select a group to open its component table.
Models: МШР-1500х5600, МШР-3200х4500, МШР-3600х4000, МШР-3600х5000, МШР-4000х5000, МШР-4500х5000
| No. | Component | Location |
|---|---|---|
| 1 | Shell | Main body of the mill |
| 2 | End cover | |
| 3 | Model-specific component | |
| 4 | Ring gear | |
| 5 | Drive shaft assembly | |
| Model-specific component |
The Grate-discharge ball mills covers 6 models: МШР-1500х5600, МШР-3200х4500, МШР-3600х4000, МШР-3600х5000, МШР-4000х5000, МШР-4500х5000. Former and renamed designations are listed in the models table on this page.
The Grate-discharge ball mills is also documented under these designations: МШР-1500х5600, МШР-3200х4500, МШР-3600х4000, МШР-3600х5000, МШР-4000х5000, МШР-4500х5000.
The Grate-discharge ball mills is listed under the NKMZ brand. Status: Historical model.
6 components are recorded, including: Shell, End cover, Ring gear, Drive shaft assembly and more. The full list with locations is in the components table on this page.
