2024 —2026 · 1 model
Select a model to jump to its component table; former and renamed designations are listed under “Historical names / renamings”.
| Model | Historical names / renamings | Period | Components |
|---|---|---|---|
| LTM | LTM 1450-8.1; LTM 1300-6.2; LTM 1150-5.3; LTM 1160-5.2; LTM 1230-5.1; LTM 1250-5.1; LTM 1030-2.1; LTM 1040-2.1; LTM 1050-3.1; LTM 1055-3.3; LTM 1060-3.1; LTM 1070-4.2; LTM 1090-4.2; LTM 1090-4.3; LTM 1120-4.2; LTM 1100-5.3; LTM 1110-5.2; LTM 1150-5.4; LTM 1650-8.1; LTM 1750-9.1; LTM 11200-9.1; LTM 1300-6.4; LTM 1400-6.1 | 2024 —2026 | 3 |
The numbers on the diagram correspond one to one with the rows below.
| No. | Component | Location | Applies to |
|---|---|---|---|
| 1 | Hoist rope | Rope reeving between boom-head sheaves and hook block | LTM 1030-2.1 |
| 2 | Sheaves | Sheave assembly at telescopic boom head | LTM 1030-2.1 |
| 3 | Hook block | Black hook block below boom head | LTM 1030-2.1 |
Models with the same components are grouped together; select a group to open its component table.
| No. | Component | Location |
|---|---|---|
| 1 | Hoist wire rope | Boom and hook hoisting circuit |
| 2 | Sheave | Rope path at the boom head and hook block |
| 3 | Hook block assembly | Hoisting mechanism end |
The LTM is also documented under these designations: LTM 1450-8.1, LTM 1300-6.2, LTM 1150-5.3, LTM 1160-5.2, LTM 1230-5.1, LTM 1250-5.1, LTM 1030-2.1, LTM 1040-2.1, LTM 1050-3.1, LTM 1055-3.3, LTM 1060-3.1, LTM 1070-4.2, LTM 1090-4.2, LTM 1090-4.3.
The LTM is listed under the Liebherr brand. Period: 2024 —2026. Status: Historical model.
3 components are recorded, including: Hoist wire rope, Sheave, Hook block assembly. The full list with locations is in the components table on this page.
Model-specific components with their own page: Hoist wire rope, Sheave, Hook block assembly (3 in total).
