3 models
Select a model to jump to its component table; former and renamed designations are listed under “Historical names / renamings”.
| Model | Historical names / renamings | Components |
|---|---|---|
| BJD MINI-MILL No1 (7x8) | MINI-MILL No1; 7x8 | 3 |
| BJD MINI-MILL No2 (15x8) | MINI-MILL No2; 15x8 | 3 |
| BJD MINI-MILL No3 (20x12) | MINI-MILL No3; 20x12 | 3 |
The numbers on the diagram correspond one to one with the rows below.
| No. | Component | Location | Applies to |
|---|---|---|---|
| 1 | Hammer | Hammer row around the red rotor in the opened casing | Mini-Mill product family |
| 2 | Wear liner | Grey inner wall liner behind and above the rotor | Mini-Mill product family |
| Component |
|---|
| V-belt |
Models with the same components are grouped together; select a group to open its component table.
Models: BJD MINI-MILL No1 (7x8), BJD MINI-MILL No2 (15x8), BJD MINI-MILL No3 (20x12)
| No. | Component |
|---|---|
| 1 | Hammer head |
| 2 | Wear liner |
| Model-specific component |
The Mini-Mill Small type Hammer Grinder covers 3 models: BJD MINI-MILL No1, BJD MINI-MILL No2, BJD MINI-MILL No3. Former and renamed designations are listed in the models table on this page.
The Mini-Mill Small type Hammer Grinder is also documented under these designations: BJD MINI-MILL No1, MINI-MILL No1, 7x8, BJD MINI-MILL No2, MINI-MILL No2, 15x8, BJD MINI-MILL No3, MINI-MILL No3, 20x12.
The Mini-Mill Small type Hammer Grinder is listed under the BJD Crushers brand. Status: Historical model.
3 components are recorded, including: Hammer head, Wear liner and more. The full list with locations is in the components table on this page.
Send us a drawing or sample and tell us the equipment model and part name.
Provide the equipment model, drawing for engineering review and quotation. If service life or wear is a concern, describe the operating conditions as well.
