5 models
Select a model to jump to its component table; former and renamed designations are listed under “Historical names / renamings”.
| Model | Historical names / renamings | Components |
|---|---|---|
| AUBEMA 4210 / 02-15 | 4210 / 02-15 | 4 |
| AUBEMA 4210 / 03-20 | 4210 / 03-20 | 4 |
| AUBEMA 4210 / 04-25 | 4210 / 04-25 | 4 |
| AUBEMA 4210 / 05-30 | 4210 / 05-30 | 4 |
| AUBEMA 4210 / 06-35 | 4210 / 06-35 | 4 |
The numbers on the diagram correspond one to one with the rows below.
| No. | Component | Location | Applies to |
|---|---|---|---|
| 1 | Grinding rods | Grinding media inside the upper and lower tubes | 4210 twin-drum design family; individual size installations may differ |
| 2 | Grinding tubes | Upper and lower grinding tubes | 4210 twin-drum design family; individual size installations may differ |
| 3 | Helical springs | Supports below the vibrating body | 4210 twin-drum design family; individual size installations may differ |
| Component |
|---|
| Mill shell liner |
| Rubber air spring |
Models with the same components are grouped together; select a group to open its component table.
Models: AUBEMA 4210 / 02-15, AUBEMA 4210 / 03-20, AUBEMA 4210 / 04-25, AUBEMA 4210 / 05-30, AUBEMA 4210 / 06-35
| No. | Component |
|---|---|
| 1 | Grinding rod |
| 3 | Screw spring |
| Model-specific component | |
| Model-specific component |
The 4210/02-15 etc. covers 5 models: AUBEMA 4210 / 02-15, AUBEMA 4210 / 03-20, AUBEMA 4210 / 04-25, AUBEMA 4210 / 05-30, AUBEMA 4210 / 06-35. Former and renamed designations are listed in the models table on this page.
The 4210/02-15 etc. is also documented under these designations: AUBEMA 4210 / 02-15, 4210 / 02-15, AUBEMA 4210 / 03-20, 4210 / 03-20, AUBEMA 4210 / 04-25, 4210 / 04-25, AUBEMA 4210 / 05-30, 4210 / 05-30, AUBEMA 4210 / 06-35, 4210 / 06-35.
The 4210/02-15 etc. is listed under the AUBEMA brand. Status: Historical model.
4 components are recorded, including: Grinding rod, Screw spring and more. The full list with locations is in the components table on this page.
